Image Sensor

1/3" SONY

1/3" SHARP

1/3" SONY

1/3" SHARP

1/3" SONY

1/3" HDIS

Horizontal Resolution

1.3Megapixel Sensor,720P, Low Illumination, IR-CUT,3D NR, Digital Zoom, OSD

960H, 700TVL, Low Illumination, Real WDR, OSD, 3D NR, UTC Effio-P

960H, 700TVL, Low Illumination, DWDR, OSD, DNR, UTC Effio-E

960H, 700TVL, Low Illumination, Super WDR, 3D NR, Demist, SLR, Sense-up, UTC, OSD (Auto Iris with ICR add USD5)

700TVL, Low Illumination, DWDR, OSD, DNR

650TVL, Low Illumination, DWDR, OSD, DNR

600TVL, Low Illumination

500TVL, Low Illumination

700TV Lines Low Illumination

Pixels

NTSC:976(H)×494(V),
PAL:976(H)x582(V )

N:768(H)×494(V,
P:752(H)x582(V)

P:752(H)×582(V)
N:768(H)×494(V)

P:500(H)×582(V)
N:510(H)×492(V)

728(H)×488(V)

TV System

PAL/NTSC

IR range

25M

Lens

2.8-12mm Manual Zoom Lens (2M Pixels)

IR LED

￠5X30PCS

Sync System

Internal

Usable Illumination

0.001Lux/F2.0

0.01Lux/F2.0

0.001Lux/F2.0

S/N Ratio

≥52dB (AGC OFF)

≥48dB (AGC OFF)

≥46dB (AGC OFF)

Gamma Correction

0.45

Video Out

Composite Signal (1.0Vp-p, 75Ω)

Scanning System

PAL:625 Lines, 50 Field/Sec;NTSC:525 Lines, 60 Field/Sec

Electronic Shutter Time

Auto:PAL 1/50-1/100, 000Sec;NTSC 1/60-1/100, 000Sec

Operation  Temperature

-10℃ ~ +50℃ RH95% Max

Storage  Temperature

-20℃ ~ +60℃ RH95% Max

White Balance

Auto

Power Source

DC12V 350mA

Dimension

￠136x 95(H) mm

Weight

1.1Kg
