IR LED: ¢5X24PCS IR range: 20M
IR LED: ¢5X24PCS IR range: 20M
Board Lens 3.6mm/F2.0
Water resistance: IP66
3-Axis cable built-in bracket
Size: 148(W) x 65(H) x 63(D)mm
Weight: 500g
Image Sensor
|
1/3" HDIS
|
1/3" SONY
|
1/3" SHARP
|
1/3" SONY
|
1/3" SHARP
|
1/3" SONY
|
Horizontal Resolution
|
700TVL, with IR-CUT
|
960H, 700TVL, Low Illumination, DWDR, OSD, DNR,
UTC Effio-E
|
960H, 700TVL, Low Illumination
|
650TVL, Low Illumination, DWDR, OSD, DNR
|
600TVL, Low Illumination
|
500TVL,
Low Illumination
|
Pixels
|
728(H)×488(V)
|
NTSC:976(H)×494(V),
PAL:976(H)x582(V )
|
NTSC:768(H)×494(V),
PAL:752(H)x582(V)
|
PAL:752(H)×582(V),
NTSC:768(H)×494(V)
|
PAL:500(H)×582(V)
NTSC:510(H)×492(V)
|
TV System
|
PAL/NTSC
|
IR LED
|
¢5X24PCS
|
IR Series Distance
|
20M
|
Lens
|
Board Lens 3.6mm/F2.0
|
Sync System
|
Internal
|
Usable Illumination
|
0.001Lux/F2.0
|
0.0005Lux/F2.0
|
S/N Ratio
|
≥46dB (AGC OFF)
|
≥56dB (AGC OFF)
|
≥48dB (AGC OFF)
|
Gamma Correction
|
0.45
|
Video Out
|
Composite Signal (1.0Vp-p, 75Ω)
|
Scanning System
|
PAL:625 Lines, 50 Field/Sec;NTSC:525 Lines, 60
Field/Sec
|
Electronic Shutter Time
|
Auto:PAL 1/50-1/100, 000Sec;NTSC 1/60-1/100,
000Sec
|
Operation Temperature
|
-10℃ ~ +50℃ RH95% Max
|
Storage Temperature
|
-20℃ ~ +60℃ RH95% Max
|
White Balance
|
Auto
|
Power Source
|
DC12V 300mA
|
Dimension
|
148(W) x 65(H) x 63(D)mm
|
Package
|
52*39*34mm 40PCS/CTN
|
Weight
|
500g
|
